High Efficiency 1212 5 Axis CNC Router With ATC

The 5-axis 1212 ATC CNC router has a worktable size of 1200*1200mm. It is capable of movement along 5 axes, enabling the creation of complex 3D designs with exceptional precision.

AKM1212-5A CNC Router

(4 customer reviews)

$60,900.00

Model: AKM1212-5A
Barnd: AccTek CNC
Spindle: Hiteco
Drive Mode: Yaskawa Servo Motor and Driver
Control System: Syntec 610MA-E5
Table of Contents

Product Description

The 5-axis 1212 ATC CNC router is a cutting-edge precision machining tool with unparalleled versatility and automation capabilities. Capable of moving along five axes, the machine offers unparalleled freedom in cutting, routing, and processing materials, allowing it to create complex 3D designs with exceptional precision. Its workbench size is 1200*1200mm, making it suitable for various industries, including aerospace, automotive, woodworking, etc. The ATC function automatically changes tools while processing the device, thereby reducing downtime and increasing efficiency. The 5-axis 1212 ATC CNC router is a state-of-the-art machining solution acclaimed for its precision, versatility, and automation. It is the first choice for businesses and industries requiring complex and multifaceted machining tasks, delivering superior results in a relatively compact workspace.

Product Configuration

Italian Hiteco 5-Axis Water-Cooled Spindle

Italian Hiteco 5-Axis Water-Cooled Spindle

The machine uses a Hiteco 5-axis water-cooled spindle. It is designed for 5-axis CNC machines and uses a water cooling system to maintain ideal operating temperatures. This precision spindle ensures consistently high performance, making it suitable for use in industries requiring complex, multi-directional machining. Water cooling enhances heat dissipation and extends spindle life, resulting in better-cut quality and increased efficiency.

Taiwan Syntec 610MA-E5 System

The machine is equipped with Taiwan’s Syntec 610MA-E5 system, which provides advanced features for precision machining, automation, and flexibility. It can be a CNC router capable of precisely controlling multi-axis motion, spindle speed, and tool changes. The Syntec 610MA-E5 system features a user-friendly interface, powerful processing capabilities, and good compatibility with a variety of machine types.
Taiwan Syntec 610MA-E5 System
Vacuum Worktable With Double-Stage Air Pump

Vacuum Worktable With Double-Stage Air Pump

The machine is equipped with a vacuum worktable that ensures the workpiece remains firmly in place throughout the CNC routing process. The powerful vacuum system grabs your material reliably and evenly, preventing unwanted movement and ensuring precise, error-free results. In addition to improving accuracy, vacuum worktables ensure a safe and clean workspace. The pump requires minimal maintenance, saving you valuable time and reducing operating costs, ensuring your CNC router operates at its best for a long time.

Yaskawa Servo Motor

The machine uses Yaskawa servo motors, which can work seamlessly with Yaskawa motion controllers and drives to precisely control speed, position, and torque, resulting in excellent precision and accuracy. The motor offers fast response times and is able to quickly adapt to changes in position and speed, allowing it to handle dynamic and demanding tasks.
Yaskawa Servo Motor
Hiwin Guide Rail

Taiwan Hiwin Guide Rail

This machine uses Taiwan Hiwin guide rails, which provide unparalleled stability, ensuring your machine’s motion is rock solid, eliminating vibration, and guaranteeing the accuracy you need. The Hiwin guide rails are durable and focus not only on accuracy but also on durability. It’s built to withstand the rigors of continuous operation, delivering the longevity and reliability professionals rely on.

Japanese SMC Pneumatic Element

The machine uses a Japanese SMC pneumatic element to ensure precise control of clamping, tool changing, and workpiece positioning, helping to achieve high machining accuracy. Its sturdy construction and long service life reduce maintenance downtime and increase the overall efficiency of the machine. Additionally, it provides efficient air management, ensuring fast and reliable tool changes.
Japanese SMC Pneumatic Element
Double Bag Dust Collector

Double Bag Dust Collector

The machine features a dual-bag dust collector designed to effectively eliminate dust and debris generated during CNC operations. Equipped with dual collection bags, it ensures complete removal of waste, keeping your workspace clean and your machine running optimally. It’s more than just an accessory, it’s your commitment to cleanliness, air quality, and a more efficient workspace.

Automatic Oil Lubrication System

The machine is equipped with an automatic oil lubrication system that ensures consistent and precise lubrication of critical machine components, reducing wear and friction. Automatic oil lubrication systems eliminate the need for manual lubrication, saving time and reducing the risk of human error. It also provides optimal oil distribution, preventing over or under-lubrication.
Automatic Oil Lubrication System

Table Design Selection

Sunken Worktable

Sunken Worktable

The sunken worktable accommodates higher workpiece heights and provides flexibility for integrated rotary axes, taking your process capabilities to new heights. Additionally, a sunken worktable goes beyond the limitations of a traditional tabletop worktable by providing a solid foundation for your workpiece.

Desktop Worktable

Desktop Worktable

Benchtop worktable is all about flexibility. If you need flexibility and unrestricted handling of a variety of CNC projects, this design is the best choice for you, allowing you to load and unload materials easily and freely. It gives you adaptability and efficiency no matter what project you're working on.

Product Features

  • The machine can operate on 5 axes, providing full 5-axis simultaneous machining capabilities, providing superior flexibility in cutting and routing.
  • The ATC feature allows automatic tool changes during machining, reducing downtime and increasing productivity, and it can accommodate a variety of tools to complete a variety of tasks.
  • The machine has a spacious workbench measuring 1200×1200mm (approximately 4 feet x 4 feet) to accommodate a variety of workpiece sizes.
  • The machine’s exceptional precision and accuracy make it ideal for complex, detailed, and high-tolerance machining tasks.
  • The machine is compatible with a variety of materials, including wood, plastic, metal, composite materials, etc., meeting different applications in various industries.
  • The machine comes with user-friendly software for programming and controlling the CNC router, ensuring it can be used by operators of all skill levels.
  • The machine comes with a dust collection system that minimizes dust and debris to keep the workspace clean and safe.
  • The machine is equipped with a powerful, high-speed spindle that ensures efficient cutting and engraving, as well as fast material removal.

Technical Parameters

Model AKM1212-5A AKM1224-5A AKM1325-5A AKM1530-5A
Working Area 1200x1200x600mm 1200×2400×600mm 1300×2500×600mm 1500×3000×600mm
C Axis (Rotary Axis) ±360°
B Axis (Swing Axis) ±110°
Framework Cast steel structure
Spindle Italian Hiteco 10kw 5-axis spindle with industry water chiller
Rotating Speed 6000-24000 rpm/min
Tool Magazine Disc-type ATC (with 8 tools) or Linear-type ATC (with 8 tools)
Drive Motors Yaskawa servo motor
Guide Rail Hiwin 30mm linear guide rail
X, Y, Z Axis Transmission X, Y axis rack and pinion rack, Z axis Taiwan TBI ball screw
Repositioning Accuracy ±0.03mm
Control System Taiwan syntec 610MA-E5 system

Product Applications

The 5-axis 1212 ATC CNC router is a multi-functional precision machining tool with a wide range of product applications. In the aerospace industry, it is used to manufacture complex aircraft parts and molds. In automotive manufacturing, it manufactures complex parts such as vehicle interiors and custom body panels. Woodworking and furniture production benefit from its ability to produce 3D designs, complex carvings, and moldings. This CNC router is also crucial for the production of high-quality signage, plaques and architectural elements. Its applications extend into the medical field for the production of customized prosthetics and orthopedic devices. Overall, its versatility suits industries that require precision and complex design capabilities.
