3 axis CNC Router

Top quality 1325 main door wood carving design cnc router machine

2018-08-07 16:13:21   views:

If you have any questions, pls feel free to contact me: E-mail: export11@acctekcnccom Whatsapp: +8617863818094 Skype: acctek11

Top quality 1325 main door wood carving design cnc router machine



cnc router (3).jpg

cnc router (6).jpg

cnc router (8).jpg



Product Description



- AKM1325 mainly configurations

 #Working area: 1300*2500*200mm
 #Chinese Changsheng 3.0KW water cooling spindle
 #Mach3 controller with USB port
 #Leadshine drivers M860 and 450B stepper motors(NEMA34)
 #Transmission: XY by gear, Z by Taiwan TBI ball screw
 #Taiwan Hiwin linear square 20mm rail guide
 #Vacuum table and 5.5kw vacuum water pump
 #Shanghai Fuling inverter
 #Type3 ,Artcam
 #Auto oiling system
 #Computer cabinet
 #Tool sensor, standard tool box
cnc router (2).jpg
- Technic Parameters



Working Area 1300*2500*200mm
Traveling Positioning Accuracy ±0.03/300mm
Repositioning Accuracy ±0.03mm
Table Vacuum & T-slot Table
Frame Welded Structure
X, Y axis helical rack 1.25M, Hiwin 20# Rail Linear Bearing
Z axis Hiwin Rail 20# Linear Bearing & Taiwan TBI Ball Screw
Max. Power Consumption (Without Spindle)  2.5kw~3Kw
Max. Rapid Travel Rate 33000mm/min
Max. Working Speed 25000mm/min
Spindle Power 3.0kw water cooling spindle
Spindle Speed 0-24000RPM
Drive Motors stepper or servo motor
Working Voltage AC380V/50/60Hz,3PH (Option: 220V)
Command Language G Code
Operating System Mach3 Control System with USB port
Computer Interface USB
Flash Memory 128M(U Disk)
Collet ER25
X,Y Resolution <0.01mm
Software Compatibility Type3/UcancameV9/Artcam Software
Running Environment  Temperature 0 - 45 Centigrade
Relative Humidity 30% - 75%



cnc router (1).jpg

cnc router.jpg

Sample



Material:  Stone, marble, granite, wood, MDF, soft metal, rubber, acrylic, plastic and so on.



cnc router (4).jpg



Payment & Delivery

About the delivery:

Its need about 12-15 days to produce the machine after get your deposit.

all thing is tested well,then we arrange the delivery.



About payment:

We accept Trade Assurance on Alibaba, or T/T , you can pay 30% in advance, 70% before delivery.

The machine will be produced after received your deposit.after the machine is ready, we will show you the machine photos and the testing video.

After you agree, please finish the balance.Finally.we arrange the delivery.



Services & Feedback



- Guarantee

12 months for the whole machine. Within 12 months under normal use and maintenance, if something is wrong with the machine, you will get spare part for free. Out of 12 months, you will get spare parts at cost price. You will also get technical support and service all the lifetime.



- After sales services

1.Normal machine is properly adjusted before dispatch. You will be able to use the machine immediately after received machine.

2.Besides, you will be able to get free training advice towards our machine in our factory. You will also get free suggestion and consultation, technical support and service by email/fax/tel etc.

3.Our technicians could speak English, if you need any technical support in the future, they could help you online.

cnc router (13).jpgfeedback_3.jpg

cnc machine.jpg

cnc router (10).jpg

Contact Me

I hope you can sent me email or skype,i am glad to help you choose the most suitbale machine.

And we are seeking worldwide distributors.I believe Win-win is the best way for us.



# Contact person: Abby Wang

# Skype: acctek11

# Whatsapp: +8617863818094

# E-mail: export11"at"acctekcnc.comAcrylic MDF Small CO2 Laser engraving & cutting Machine for Sale 6090
