3 axis CNC Router

4 axis rotary cnc router for wood,furniture drilling machine,cnc kit 3 axis

2018-06-01 15:17:42   views:

AKM1325 cnc router for 3D wood work 4 axis rotary cnc router for wood,furniture drilling machine,cnc kit 3 axis


4 axis rotary cnc router for wood,furniture drilling machine,cnc kit 3 axis






AKM1325 3.jpg



Application







♥Wooden door and furniture decoration industry: Solid wood door, compound door, cupboard

  door, large area plank plane carving, wood carve designs, board type furniture engraving, archaize

  annatto furniture engraving, solid wood art mural engraving and so on.



♥Wooden crafts processing: Clock frame, picture frame, calligraphy plaque, electrical counter face,

   sports equipment, thin aluminum board cutting and engraving.



♥Electronic product industry: Circuit board, insulation materials, the LED display, home appliance

  (color TV sets, washing machines, refrigerators) shell or model engraving and cutting;



♥Instrument industry: Engraving instruments 3D surface, Appearance cutting, such as cello, violin

  panel and head; guitar, erhu 3D surface engraving and cutting.



♥EVA processing industry: EVA packing materials lined engraving and cutting for tool equipment,

  medical equipment, electronic products, glass vessel.



♥Other industries: The building model, the block, aviation block, propellers, car foam mold.

Product Description





Working Area

1300*2500*200mm

Traveling Positioning Accuracy

±0.03/300mm

Repositioning Accuracy

±0.03mm

Table

vacuum  or  T-slot Table

Frame

Welded Structure

X, Y axis

helical rack 1.25M, Hiwin 20# Rail Linear Bearing

Z axis

Hiwin Rail 20# Linear Bearing & Taiwan TBI Ball Screw

Max. Power Consumption

(Without Spindle)  2.5kw~3Kw

Max. Rapid Travel Rate

33000mm/min

Max. Working Speed

25000mm/min

Spindle Power

3KW water cooling spindle

Spindle Speed

0-24000RPM

Drive Motors

stepper or servo motor

Working Voltage

AC380V/50/60Hz,3PH (Option: 220V)

Command Language

G Code

Operating System

Mach3 PC Software with USB port

Computer Interface

USB

Flash Memory

128M(U Disk)

Collet

ER25

X,Y Resolution

<0.01mm

Software Compatibility

Type3/UcancameV9/Artcam Software

Running Environment  Temperature

0 - 45 Centigrade

Relative Humidity

30% - 75%







Detailed Images





cnc router kit.jpg4 axis 1325.jpg1325 wood cnc.jpg1325 wood working.jpg


Samples



 wood cutting.jpg



After-Sales Service

1.18 months guarantee of the whole cnc router machine,We will provide the consumable parts at an agency price when you need replacement.

2. Our engineer could support you technology to your country  if  necessary.

3. Our engineer could train you on at our factory for free.

4. Our engineer could service you 24 hours online by skype, msn, QQ, or by cellphone.


Free traning.jpg



Company Information



company 1.jpg


Please contact with Alice for more information about the AKM1325 cnc router   .
