Automatic tool changer CNC Router

Heavy duty woodworking cnc router 3d milling atc cnc router machine AKM2030D

2019-08-01 15:33:48   views:

Heavy duty woodworking cnc router 3d milling atc cnc router machine price AKM2030DProduct DescriptionATC cnc router...



 Heavy duty woodworking cnc router 3d milling atc cnc router machine price AKM2030D



Product Description



2030 cnc router.jpg

cnc wood router.jpg



ATC cnc router with CCD:

cnc router machine.jpg



Advantages wood cnc router machine:
Function: Extremely heavy-duty CNC machining center,suitable for routing,drilling,cutting,edge chamfering,etc.
Construction: Whole machine table adopts high strength thick steel pipe welded.Whole working table cast by resin sand.The annealing and other heat treatment methods ensure that the whole structure is tested to the limit for sturdiness and reliability.
Spare parts: Features world top class mechanical and electronic components,e.g.Xinyue rack and pinion,Taiwan rail and ball screw,Taiwan reducer,French Schneider electrical components,which guarantee stable performance and high quality.
Precision: Excellent spare parts,accurate precision detection instrument,which make sure he machine with perfect location and working precision.
High-speed: Adopt reducer direct design,high torque,high-energy, X axis dual motor drive,runs smoothly with high efficiency.
Table:Double-layer compound grade board table design,rugged construction,non-deformation,with functions of instant adsorption and release.
Tool magazine: With an 10-slots disc type tool changer,tool changes to be performed quickly.



Technical parameters:





Description

Parameter

X,Y Working Area

2000*3000*250mm

Z Working Area

250mm

Table Size

3300*2500mm

Resolution

0.03mm

Lathe Structure

Seamless welded steel structure, better than cast iron one

X,Y Structure

Rack and pinion, gear drive,

Taiwan Hiwin H25 square guide rails

Z Structure

Taiwan TBI rolling ball screw,

Taiwan Hiwin H25 square guide rails

Max. Idling Speed

60m/min

Spindle

9.0kw spindle

Spindle Speed

0-24000r/min, variable speed

Working Voltage

AC380V/60Hz/50Hz

Motor and driver

Delta 750w servo motor and drivers

Working Mode

SERVO A2

Command

G code (HPGL,U00,mmg,plt)

Operating System

 Syntec 6MA

Diameter of Cutter

φ3.175-φ22

Cooling Mode

Air-cooling

Dust-collect Function

Yes

Work Holding

Vacuum

Tool Magazine

Disc tool changer with 12 ISO 30 tools

Gross Weight

1650KG



 Details image of atc wood cnc router:

atc cnc router.jpgcnc router atc.jpg



Samples of cnc router machine:

The machine with high efficiency and accuracy for plastic/wood/MDF/acrylic, can be used for cutting and engraving solid furniture, mahogany furniture, MDF paint door, solid wood door, composite door, cupboard door and window, beside cabinet, folding screen, ect., passing CE, ISO.

1.Wooden door and furniture decoration industry:
Solid wood door, compound door, cupboard door, large area plank plane carving, wood carve designs, board type furniture engraving, archaize annatto furniture engraving, solid wood art mural engraving and so on.

2.Wooden crafts processing:
Clock frame, picture frame, calligraphy plaque, electrical counter face, sports equipment, thin aluminum board cutting and engrving.

3.Electronic product industry:
Circuit board, insulation materials, the LED display, home appliance (color TV sets, washing machines, refrigerators) shell or model engraving and cutting.

4.Instrument industry:
Engraving instruments 3D surface, appearance cutting, such as cello, violin panel and head, guitar, erhu 3D surface engraving and cutting.

5.EVA processing industry:
EVA packing materials lined engraving and cutting for tool equipment,medical equipment, electronic products,glass vessel.

6.Other industries:
The building model, the block, aviation block, propellers, car foam mold.

2030 cnc router





Packaging & Shipping

Payment terms:

We accept: Western Union , Trade assurance on alibaba, T/T,  Western Union , Paypel , MoneyGram.

You can pay 30% in advance, 70% before delivery.
Most customers choose Trade assdurance,becs it is maximize the protection of the interests of buyers.



Package & Delivery:

The machine will be produced after received your deposit.after the machine is ready, we will show you the machine photos and the testing video.then you pay 70% balance payment,we arrange shipping for you.
The package is tandard exporrt plywood box,customized for every size machine.

cnc router packageshipping





Company Information





Jinan AccTek Machinery Company specializes in manufacturing CNC Router and Laser machines.

Since 2005 we have based in the Industrial Zone of Jinan City, Shandong Province south of Beijing.
Our main products are AccTek CNC Router and Laser engraving and cutting machines. Stock or custom configurations are our specialty. Components for our machines are sourced from world class suppliers and innovators in machine control.
These machines are used in many industries, crafts and arts businesses around the world. These include woodwork, metal and stone work, aluminum fabrication, boat building, shop fitting, mold making, to name a few.
Our dedicated and highly skilled after sales service department, sales team, and thorough quality assurance procedures mean that you can buy with confidence.
factory acctek.jpgcnc router.jpgEXHIBITIONs.jpg


After sales service:

1.1.5years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.
2.Lifetime maintenance free of charge.
3.Free training course at our plant.
4.We will provide the consumable parts at an agency price when you need replacement.
5.24 hours on line service each day, free technical support.
6.Machine has been adjusted before delivery
7.Our staff can be sent to your company to install or adjust if necessary.

cnc router (3).jpg

cnc routerwarranty
