Desktop metal and nonmetal fiber laser marking machine AK30F

2018-09-13 17:32:35   views:

If you interest in it, pls feel free to contact me: E-mail: export31@acctekcnc com Whatsapp: +86 17853465932

 Desktop metal and nonmetal fiber laser marking machine AK30F



 laser marker3.jpg



Standard configuration of fiber laser marking machine.



#. Marking area: 110*110mm / 200*200mm
#. Raycus brand 20w/30w/50w fiber laser generator (lifetime:100000h)
#. Aluminum alloy up-down table
#. Filed lens, high speed galvanometer, marking head
#. Cooling system: air cooling
#. Computer included
#. PC control system:Windows XP and win7,win8,win10
#. Control software: EZCAD
#. Marking with red point
#. Foot switch
#. Support all-English language interface
#. Suitable for most metal and nonmetal materials marking
#. 1.5 years warranty





Machine features of fiber laser marking machine.



1) Operation system: windowns xp , windowns 7 ,windows8/10

2) Support Characters , digital, series NO, Date codes

3) Various types of fonts are supported. Such as TrueType, JSF(Single line font ), DMF(Dot Matrix Font,One-Dimensional bar code, Two-Dimensional bar code , etc.

4) Common types of images are supported. (bmp, jpg, gif, tga, png, tif…)

5) Common vector images are supported. (ai, dxf, dst, plt…)

6) Flexible variable text : changes the text real time while in laser processing . Excel datasheet is supported.

7) Dometic and Imported fiber laser source.

8) Excellent optical mode, long operating life, up to 100,000hours

9) The highest electro-optical conversion efficiency, up to 80%, but gross power less than 600W

10) Small size, steady, without maintenance, easy to operate

11) High precision, suited for fine processing on all metal and some non-metal.

12) This machine adapts the fiber laser and has high electro- optical conversion rate, the quality of laser beam is good,cooling with air- cooling methods, it has smaller shape, low power and much more energy-efficient.

13) Divergent Angle is about a quarter of the pump laser semiconducto, especially mainly used in precise, fine marking,low using cost, electro-optic conversion efficiency is up to 30%.



Machine parameters of fiber laser marking machine.



1

Model

AK-30F

2

Laser power

Fiber 30W air cooling(20W/50W)

3

Working area

100*100mm/200*200mm

4

Laser Wavelength

1064nm

5

Response time

0.5ms

6

Frequency of pulse

20-100KHz

7

Max marking depth

≤7000mm/s

8

Marking lines

1-10 lines(in the marking area)

9

Minimum line width

10 micron

10

Minimum character

0.15mm

11

Repeatability accuracy

±0.002mm

12

Resolution ratio

0.1mm

13

Marking content

Text,pattern,date,bar code,etc

14

Operation system

Microsoft Windows XP or Windows 2000

15

Control software

EZCAD control software

16

Graphic format supported

bmp, jpg, gif, tga, png,tif,ai,dxf,dst,plt,etc.

17

Unit power

≤1.2KW

18

Operation temperature

5℃-40℃

19

Relative moisture

≤ 90%,no fog

20

Supply Voltage

220V/50Hz/10A



More details about fiber laser marking machine.



1. Marking head, High speed galvanometer, Fields lens.

2. Control switch, Computer.

3. Control box(fiber laser generator), Aluminum alloy up-down table, Rotary axis(optional).

.jpg



.jpg

.jpg



Samples of fiber laser marking machine.



The fiber laser marking system is suitable for Craft gifts, leather garments, advertising signs, model making, food packaging, electronic components, pharmaceutical packaging, medicine packaging, printing plate, shell plate etc. With Keyboard Laser marker,Glass laser marker, Arts laser marker, bath ware laser marker, building ceramics, beverage packaging, textile cutting, rubber products, shell plate, electronic components, leather and other industries.



laser marking machine14.jpg

laser marking machine12.jpg

 laser marking machine13.jpg



ACCTEK laser cnc machine Packaging & Delivery.





About payment:&l
